MP C3004 Multifunction Color Laser Printer

General Specifications
Configuration Desktop
Printing Process 4-Drum Method
Output Speed MP C3004: 30-ppm B&W & FC
(Copy/Print) (A4)
MP C3504: 35-ppm B&W & FC
(A4)
Warm-Up Time 25 seconds
Recovery from Approximately 1.0 second
Sleep Mode (motion sensor activated)
First Copy Time
(FC/B&W) 7.1/4.6 seconds
Copy Resolution 600 dpi
Quantity Indicator Up to 999 copies
Single Pass Document Original Capacity: 220 sheets
Feeder (SPDF) Original Size: A5 – A3
Paper Weights: Simplex: 40 – 128
g/m², Duplex: 52 – 128 g/m²
Automatic Reversible Original Capacity: 100 sheets
Doc. Feeder (ARDF)
Paper Capacity Standard: 2 x 550 sheets +
100-Sheet Bypass Tray
Maximum: 4,700 sheets (w/
Tandem LCT + Side LCT)
Supported Paper Sizes1st Paper Tray: A4
2nd Paper Tray: A6 – SRA3,
Envelopes
Bypass: Up to SRA3, Envelopes
Custom Sizes: Width: 90 – 320
mm, Length: 148 – 1260 mm
Supported Paper Standard Trays: 60 – 300 g/m²
Weights Bypass Tray: 52 – 300 g/m²
Duplex Unit: 52 – 256 g/m²
Paper Types Plain, Recycled, Special Paper 1-3,
Letterhead, Cardstock, Preprinted
Paper, Bond Paper, High-Gloss
Coated Paper, Colour Paper,
Envelopes, Coated, Labels* &
OHP*
Auto Duplex Standard
Output Capacity Standard: 500 sheets
Maximum: 1,625 sheets
Zoom 25% – 400% in 1% increments
Dimensions (WxDxH) 587 x 685 x 1210 mm
(Includes SPDF and Two-Tray
Paper Bank)
Weight 101 kg
Power Requirements 220-240V 50/60Hz
Power Consumption 1,700W or less; Sleep Mode: .93W
TEC Value** MP C3004: 1.2 kWh
MP C3504: 1.3 kWh
*Bypass Tray Only
** Typical Electricity Consumption by ENERGY STAR Qualified Imaging
Equipment Test Procedure
Printer Specifications (Standard)
CPU Intel Atom Processor Bay Trail
1.33 GHz
Memory /HDD 2 GB RAM/250GB HDD Standard
& 4GB RAM/250GB HDD Option
Page Description Standard: PCL5c, PCL6, PDF
Languages Optional: Adobe® PostScript®3™,
PictBridge, XPS
Font Support Standard: PCL: 45 Scalable fonts
+ International 13 fonts
Optional: PostScript 3: 136
Roman fonts
Max. Print Resolution 1200 x 1200 dpi
Network Interfaces Standard: 1000Base-T/100BaseTX/ 10Base-T Ethernet, USB2.0
Type A (3 Ports), SD Slot on
Operation Panel Option: EEE1284/
ECP; IEEE802.11a/b/g/n; USB2.0
Type B
Network Protocol
Support TCP/IP (IPv4, IPv6)
Network/OS Windows® Vista/7/8/8.1/10/
Server 2008/ Server 2008R2/
Server2012/Server 2012R2
Unix; Sun Solaris, HP-UX, SCO
OpenServer, RedHat Linux, IBM
AIX, Citrix Presentation Server4.5,
XenApp 5.0, Mac OS X v.10.7
or later, SAP R/3, IBM iSeries
AS/400-using OS/400 Host Print
Transform
Utilities Device Manager NX Series, Web
Image Monitor, @Remote
Document Server Specifications
(Standard)
Max. Stored Documents 3,000
Max. Pages/Document 2,000
Max. Page Capacity 9,000
Max. Number of Folders 200
Scanner Specifications (Standard)
Scanner Resolution B&W and FC scanning at 100
– 600 dpi, Up to 1200 dpi for
TWAIN scanning
Scanning Speed 200/300 dpi: 110 ipm Simplex/
(B&W & Full-Colour 180 ipm Duplex
A4)
Scan Area 297 mm – 432 mm
Compression Method B&W TIFF: MH, MR, MMR, JBIG2
Full-Colour: JPEG
Supported File
Formats Single/Multi-Page TIFF, PDF, High
Compression PDF & PDF/A Single
Page JPEG
Scan Modes Scan-to-Email (with LDAP
support)
Scan-to-Folder (SMB/FTP)
Scan-to-URL
Scan-to-Media (USB/SD Card)
Network TWAIN Scanning
Facsimile Specifications (Optional)
Type ITU-T (CCITT) G3
Circuit PSTN, PBX
Resolution 200 x 100 dpi, 200 x 200 dpi,
400 x 400 dpi (with optional SAF
memory)
Modem Speed 33.6K – 2,400 bps w/Auto
Fallback
Compression Method MH, MR, MMR, JBIG
Transmission Speed G3: Approximately 2 seconds/
page (JBIG)
Scanning Speed Up to 81 spm
Auto Dialing 2,000 Quick/Speed Dial numbers;
100 Group Dial numbers
Memory Capacity Standard: 4 MB (approx. 320
(SAF) pages),
Optional: 64 MB (approx. 4,800
pages) with optional SAF memory
RICOH MP C3004/MP C3504
SYSTEM SPECIFICATIONS
Security Features (Standard)
DataOverwriteSecurity System (DOSS), HDD Encryption, User Codes, SNMP v3
Support, Encryption, Locked Print, User Authentication, 802.1x Wired Authentication,
Quota Setting/Account Limit, Digitally Signed PDF, and more
Hardware Accessories
Paper Handling Options
Two-Tray Paper Bank (PB3160)1
Tray Capacity 1,100 sheets (550 sheets x 2 trays)
Paper Size A5 – SRA3
Paper Weight 52 – 300 g/m2
Dimensions (WxDxH) 587 x 685 x 247 mm
One-Tray Paper Bank (PB3150)1
Tray Capacity 550 sheets x 1 tray
Paper Size A5 – A3
Paper Weight 52 – 300 g/m2
Dimensions (WxDxH) 587 x 685 x 120 mm
Requires installation of Caster Table Type M3
Tandem Large Capacity Tray (PB3230)1
Tray Capacity 2,000 sheets (1,000 sheets x 2)
Paper Size A4
Paper Weight 52 – 300 g/m2
Dimensions (WxDxH) 587 x 685 x 247 mm
Side Large Capacity Tray (RT3030)
Tray Capacity 1,500 sheets
Paper Size A4
Paper Weight 52 – 300 g/m2
Dimensions (WxDxH) 340 x 545 x 290 mm
Requires installation of Two-Tray Paper Bank (PB3160) or Tandem LCT (PB3230)
Output Trays & Finisher Options
Internal Shift-Sort Tray (SH3070)3
Tray Capacity 250 sheets (A4 or smaller)
125 sheets (B4 or larger)
Paper Size A5 – SRA3
Paper Weight 52 – 300 g/m2
Cannot be installed with any Finisher
1 Bin Tray (BN3110)
Paper Size A5 – SRA3
Paper Weight 52 – 300 g/m2
Tray Capacity 125 Sheets
250-Sheet Stapleless Internal Finisher (SR3180)
Paper Size A6 – A3
Paper Weight 52 – 300 g/m2
Stack Capacity 250 sheets (A4)
125 sheets (B4 – A3)
Staple Paper Size A4 – A3
Staple Paper Weight 64 – 80 g/m2
Stapleless Capacity 2 – 5 sheets/set
Staple Positions Top, 1 Staple
Dimensions (WxDxH) 435 x 515 x 150 mm
500-Sheet Internal Finisher (SR3130)3
Paper Size A6 – A3
Paper Weight 52 – 300 g/m2
Stack Capacity 500 sheets (A4 or smaller)
250 sheets (B4 or larger)
Staple Paper Size A4 – A3
Staple Paper Weight 52 – 105 g/m2
Staple Capacity 50 sheets (A4)
30 sheets (B4 – A3, and/or Mixed Sizes)
Staple Positions Top, Bottom, 2 Staples
Dimensions (WxDxH) 546 x 523 x 170 mm
2-/4-Hole Punch Unit (PU3040EU)
(Optional; Installs inside SR3130 Internal Finisher)
Punch Paper Sizes A4 – A3
Punch Paper Weight 52 – 169 g/m2
1,000-Sheet Hybrid Staple + Stapleless Finisher (SR3210)2 3 4
Paper Size Proof Tray: A6 – A3
Shift Tray: A6 – A3
Paper Weight Proof Tray: 52 – 169 g/m2
Shift Tray: 52 – 300 g/m2
Stack Capacity Proof Tray: 250 sheets (A4 or smaller); 50
sheets (B4 or larger) Shift Tray: 1,000 sheets
(A4 or smaller); 500 sheets (B4 or larger)
Ricoh Australia Pty. Ltd. Suite G2, 2 Richardson Place, North Ryde, NSW, 2113. Phone: 13 RICOH (13 74264) Fax: (02) 9249 6244 Web: ricoh.com.au
Ricoh New Zealand Pty. 60 Stanley Street, Parnell, Auckland New Zealand. Phone: 0800 2 Ricoh (0800 2 74264) Fax: 09 915 1401 Web: ricoh.co.nz
Stapleless Capacity 2 – 5 sheets/set
Staple Capacity 50 sheets (A4 or smaller)
30 sheets (B4 or larger)
Staple Paper Size A4 – A3
Staple Paper Weight 52 – 105 g/m2
Staple Positions Top, Bottom 2 Staples
Dimensions (WxDxH) 563 x 620 x 960 mm
2-/4-Hole Punch Unit (PU3050EU)
(Optional; Installs inside SR3210 or SR3220 Finisher)
Punch Paper Sizes A4 – A3
Punch Paper Weight 52 – 256 g/m2
1,000-Sheet Booklet Finisher (SR3220)2 3 4
Paper Size Proof Tray: A6 – SRA3
Shift Tray: A6 – A3
Paper Weight Proof Tray: 52 – 169 g/m2
Shift Tray: 52 – 300 g/m2
Stack Capacity Proof Tray: 250 sheets (A4 or smaller); 50
sheets (B4 or larger) Shift Tray: 1,000 sheets
(A4 or smaller); 500 sheets (B4 or larger
Staple Capacity Normal Staple: 50 sheets (A4 or smaller);
30 sheets (B4 or larger)
Saddle Stitch 15 sheets
Staple Paper Size Normal Staple: A4 – A3
Saddle Stitch: A4 – A3
Staple Paper Weight 52 – 105 g/m2
Staple Positions Top, Bottom, 2 Staples, Booklet
Dimensions (WxDxH) 563 x 620 x 960 mm
Colour Controller E-23C
Controller Type Embedded Type
Fiery Platform FS150
CPU Intel Processor G850 2.9GHz
Host Interface 1000Base-T/100Base-TX/10Base-T
Memory 2 GB
Internal HDD 500 GB
Operating System Linux
Network Protocol TCP/IP (IPv4/IPv6), SMB, Bonjour
Printer Description Standard: PostScript 3 & PCL6/5c
Language
Max Print Resolution Up to 1200 dpi (2 bit)
Max Scan Resolution Up to 600 dpi
Fonts PS3: 138 fonts/PCL: 81 AGFA fonts
Utilities Standard: Command WorkStation® 5,
Fiery® Scan, Printer Delete Utility, Fiery Web
Tools, Fiery Bridge, Secure Erase and Fiery
VUEOptional: Fiery Impose, Fiery Compose,
Fiery Auto Trap, EFI Spot-On™, Fiery Hot
Folders, Fiery Colour Profiler Suite v4.0,
Fiery ES-2000 Spectrophotometer
Colour Management ICC Profile, Colour Chart, CMYK Colour
Tools Reference Pages, RGB Colour Tests,
Trapping Support and ColourWise® Pro
Tools
